接口主机接口：USB3.0 ( SuperSpeed ) UVC / USB2.0 ( High-Speed ) UVC

规格

型号	TC-UB570 Pro
最大输入	1920×1080p@60/50fps
录制模式	Software   Compression, Real-Time Mode
接口	USB3.0 ( SuperSpeed ) UVC /   USB2.0 ( High-Speed ) UVC
视频输入	1×SDI, 1×HDMI, 1×DVI-I,   1×YPbPr, 1×CVBS, 1×S-Video
视频裸数据格式	YUY2
视频输入分辨率	USB2.0/3.0 Support Resolution All resolution below 1920×1200p@60fps
录制视频格式	YUY2 (   USB2.0/3.0 )
UVC 视频输出分辨率	USB3.0 Support Resolution 1920×1200p@60/50/30/25/24fps 1920×1080p@60/50/30/25/24fps 1280×1024p@60/50/30/25/24fps 1280×720p@60/50/30/25/24fps 1024×768p@60/50/30/25/24fps 800×600p@60/50/30/25/24fps 640×480p@60/50/30/25/24fps 720×576p@60/50/30/25/24fps 720×480p@60/50/30/25/24fps USB2.0 Support Resolution 640×480p@30/25/24fps 720×576p@25/24fps 720×480p@25/24fps
音频输入	SDI Embedded Audio HDMI Embedded Audio 2×RCA ( Audio L/R Through Component Cable )
音频格式	Stereo / 16-bit / 48000Hz
操作系统	Windows 7 / Windows 8.1 / Windows 10 ( 32-bit and 64-bit ) Linux / MAC OS / Android
